首頁 > 產品中心 > 噴砂機系列噴砂機系列
◆主要技術參數 Main technical parameters
|
機器型號 Model |
1立方雙槍電控噴砂機 |
2立方雙槍電控噴砂機 |
|
|
磨料桶直徑 Abrasive drum diameter (mm) |
1000 |
1500 |
1500 |
|
高度 Height(mm) |
1550 |
2000 |
2500 |
|
磨料桶容積 Abrasive drum volume (m3) |
1.0 |
2.0 |
3.0 |
|
氣源壓力 Pressure(bar) |
0.5-0.8Mpa |
0.5-0.8Mpa |
0.5-0.8Mpa |
|
噴槍數量 Spray gun quantity |
2 |
1-10 |
6 |
|
噴嘴直徑 Nozzle diameter (mm) |
￠8-￠12 |
￠8-￠12 |
￠8-￠12 |
|
裝砂量 Outfit sand amount |
剛玉砂/1500kg; 鋼砂/2500kg |
剛玉砂/3000kg; 鋼砂/5000kg |
剛玉砂/4500kg; 鋼砂/7500kg |
|
氣源 Air source |
10-16m3/min |
6-40m3/min |
30-48m3/min |
|
效率 Efficiency (m2/h) |
40-60 |
20-200 |
120-250 |
◆產品特點 Product features
1. 可移動操作，功能全，配套齊，操作簡單方便。
2. 只要具備壓縮空氣源，就能進行高效率的表面清理及光飾噴砂處理。
3. 可根據需要選擇手控式或電控噴砂操作方式。
1. Mobile operation, complete functions, perfect facilities, and convenient operation.
2. As long as have compressed air source, can perform high efficiency of the surface cleaning and light act the role ofing sandblasting processing.
3. Can choose hand control or the electric control gush arenaceous operating mode according to need.
◆適用范圍 Applicable scope
適用于大型工件的噴砂處理(如鋼結構、船舶修造、鋼板、鍋爐、集裝箱等)清理工作，服裝行業牛仔服修飾噴砂。
Application: apply to large workpieces piating (such as steel structure, ship building, steel plates, boiler, container, etc) clean up, jeans garment industry to modify sandblasting.
