第四代新款氣動型高壓無氣噴涂機，，一機拖雙槍，與進口噴涂機同等水平。
1、本公司生產的第四代無氣噴涂機，設有自動切削冰塊功能，冬天不易冰死，基本解決了此難題。
2、在同行業產品中，在噴涂中有至命的死點無法解決，造成停機、打開觀察檢驗，把換向活塞往下壓后，有的撥動滑塊重新啟動，本公司排除了這一難題。
3、在噴涂中時有脈沖，由于氣路分布不均勻，造成脈沖的原因，基本解決。
4、同類產品中不耐磨，調試后打開新氣缸檢驗，氣缸內壁拉成多條直線傷痕，造成見不到的內漏。本公司生產的氣缸壽命是同類產品三倍以上，不易拉傷和磨損。
The fourth generation of new type high pressure pneumatic without gas it, leading technology, a machine gun, and the import of drag it the same level.
1. the company produced the fourth generation of it, no gas with automatic cutting ice function, winter ice death, not easily solved the difficult problem. Basic
2. in the domestic industry products, have to life in spray of dead spots caused by cannot be solved, stop, turn the observation, reversing the pistons inspection after lifting, some turn the slider to restart, this company ruled out this problem.
3. in spray, often because gas path pulse, uneven distribution, the reason caused pulse, basic solution.
4. similar products in the wear-resisting, after testing new cylinder inspection, open the cylinder wall DuoTiao drawn into a straight line, see the wound caused by leakage. This company produces the cylinder life is the same kind products three times, not easy strain and wear. At present, it is the leader in the manufacturing industry.
◆產品簡介 Product introduction
新型氣動型高壓無氣噴涂機現已研制一機拖雙缸的設備，可代替進口設備，大大減低了各使用單位的成本，深受廣大用戶的評價。本公司的產品與市場的零部件通用，我公司生產的新一代噴涂機設有自動安全閥，對設備和人身具有安全性。新型的設計和裝置、不易頂缸，對設備氣動后大大減低了振動力，延長設備壽命。
噴涂設備系列
◆產品特點 Product features
無氣噴涂設備以壓縮空氣作動力,適合于所有壓縮空氣的場所配備氣動換向動力頭；具有立式、壁掛式、手提式、小車式、升降式多種安裝形式。
1、需長效防腐的施工涂料的噴涂。如：厚漿型環氧瀝青涂料、改性環氧涂料、環氧天然氣母氧化鐵涂料、高固體份無溶劑環氧涂料、超強環氧涂料、可復涂聚氨脂涂料等新型高性能涂料；
2、各種常規涂料，如：氯化橡膠涂料、酚醛、醇酸、氨基、硝基、丙烯酸、建筑乳膠漆等涂料；
3、還可以用于礦井等落差較大的地方進行液體的高壓輸送。船舶、汽車、鐵道車輛、集裝箱、管道、儲罐、橋梁、水閘等大型構件的涂裝。無氣噴涂設備以壓縮空氣作動力,采用新型換向動力頭，穩定可靠，故障率低；
No gas spraying equipment’s power is compressed air. It is suitable for all the place of compressed air with pneumatic reversing power head; Has the vertical, wall hung, portable, trolley type, lift type and many other installation forms.
1、Need to long-term anti-corrosion coating spray of construction high difficulty. Such as: high-build pitch epoxy coating, modified epoxy coating, iron oxide coating, epoxy gas mother ,High solids epoxy coating and without solvent Super epoxy coating, but after besmear polyurethane coatings and so on the new high performance coatings;
2、All kinds of conventional coatings, such as: chlorinated rubber paint, phenolic, alkyd, amino, nitro, acrylic acid, building emulsioni paint, etc.
3、It can also used for the high pressure can be liquid transportation that mine industries where the large gap. Ship, automobile, railway vehicle, container, pipelines, storage tanks, Bridges, locks and other large component of the painting. No gas spraying equipment’s power is compressed air. It is new type head, and stable and reliable power reversing, low fault rate;
◆無氣噴涂機與應用 Spraying machine without gas and application
噴涂機是采用高壓無氣噴涂技術用噴涂設備。高壓無氣噴涂，也稱無氣噴涂，它使用高壓柱塞泵，直接將油漆加壓。形成高壓力的油漆，噴出槍口形成霧化氣流作用于物體表面（墻面或木器面）。相對于有氣噴涂而言，漆面均勻，無顆粒感，由于與空氣隔絕，油漆干燥干凈。無氣噴涂可用于高粘度油漆的施工，而且邊緣清晰，甚至可用于一些有邊界要求的噴涂項目。視機械類型，也分為氣動式無氣噴涂機、電動式無氣噴涂機、內燃式無氣噴涂機等多種。
主要適用于噴涂：航天航空、船舶修造、中國海事、石油管道、核電站、鋼結構、各種防水涂料、外墻、石頭漆、防火隔熱材料、浮雕特殊效果、膩脂等！滿足了基本常用的建筑噴涂的需求。
It is the high pressure gas spraying technology without special spraying equipment. High pressure spraying, also say to do not have gas without gas spraying, it USES high pressure piston pump, directly will paint pressure. High pressure formation of paint, spouting muzzle form atomized air flow in the role of surface (metope or wood surface). Relative to character, spray paint of uniform, no grain feeling, with air separation, paint dry clean. No gas spraying can be used in the construction of high viscosity paint, and clear, even can be used in the edge of some of the spraying project boundary requirements. Depending on the mechanical type, also divided into pneumatic type no gas, no gas it-response it, no gas and diesel type it DuoZhong.
Mainly used in the spraying: aerospace, ship building, China maritime, oil pipeline, nuclear power station, steel structure, all kinds of waterproof coating, outer wall, stone paint, fire prevention insulation material, anaglyph effect of fat, such as special!!!!! Meet the basic of the most common building needs. Spray
◆主要技術參數 Main technical parameters
|
型號 Type |
壓力比 Pressure ratio |
涂料排量 Coating emissions |
進氣壓力 Inlet pressure |
最大噴阻號 Biggest spray resistance |
空氣消耗量(L/min) Air consumption |
|
65B |
65：1 |
2.5 |
0.3-0.6 |
050-50 |
200-2000 |
|
65C |
65：1 |
2.5 |
0.3-0.6 |
050-50 |
200-2000 |
|
55A |
55：1 |
2.5 |
0.3-0.6 |
050-50 |
200-2000 |
|
32A |
32：1 |
2.5 |
0.3-0.6 |
050-50 |
200-2000 |
|
45A |
45：1 |
2.5 |
0.3-0.6 |
050-50 |
200-2000 |
|
備注: 0.9-1m3空壓機涂料排量以噴咀大小流量為準 Note: 0.9-1m3 Air compressor's coating emissions is to nozzle size flow as the standard | |||||
無氣噴涂設備以壓縮空氣作動力,采用新型換向動力頭，穩定可靠，故障率低；壓力脈動小，涂膜均勻，涂裝質量好。
1、行程長、排量大，換向頻率低，不易磨損，整機壽命及維修周期長；
2、采用新型消音器，排氣噪聲低到至75-90dB；
3、小車式，結構緊湊，移動方便；
4、適合噴涂厚漿型高粘度涂料及全中常規涂料，滿足重防腐需求。
No gas spraying equipment’s power is compressed air. It is new type head, and stable and reliable power reversing, low fault rate; The pressure pulsation is small, the film is uniform, coating quality is good.
1. Longer journeys, and large displacement, reversing low frequency, is not easy to wear, the life and maintenance cycle is long;
2. The new type of exhaust muffler, lowest noise is 75-90dB;
3. Small car type, the structure is compact, and mobile is convenient;
4. Suitable for spraying high-build high viscosity paint and all the conventional coating, meet the requirement of the heavy anti-corrosion.
Note: our company's no gas wall spray system can it for 16-1500 mm diameter of pipe wall between on spray, if you need further information please consult my company coating division!
